NEW Advance HCD400A Heavy Duty Marine Gearbox 3.96:1 Reduction

Description

Advance HCD400A Heavy Duty Marine Hydraulic Gearbox For Commercial Applications and option for Live PTO

Available in the following ratio options:

3.96:1 (0.45hp/RPM)
4.33:1 (0.45hp/RPM)
4.47:1 (0.45hp/RPM)
4.70:1 (0.45hp/RPM)
5.00:1 (0.45hp/RPM)
5.53:1 (0.40hp/RPM)
5.70:1 (0.37hp/RPM)
5.89:1 (0.37hp/RPM)

Max Input Speed 1800RPM

Adaptor Plate Options:

SAE1
SAE0

Control Options:

Mechanical
Electronic

Drive Plate Options:

14”
16”
18”

Option for Live PTO

Option for Gearbox Oil Cooler

Weight 1100KG

Drop Centre 355mm

Dimensions 843x1010x1066 mm
