Description
Paguro 14000 Generator – Professional Overview
The Paguro 14000 Generator is part of the Paguro range of compact diesel generators developed for applications where dependable electrical power must be delivered from a relatively compact installation.
The three-phase version is particularly suited to installations requiring 400V electrical output at 50 Hz, making it relevant to marine vessels, commercial craft, onboard systems and other applications using three-phase electrical equipment.
The generator uses a Lombardini 1003 three-cylinder diesel engine and a permanent-magnet generator system. Manufacturer documentation identifies the Paguro 14000 3PH as producing 14.0 kVA and 11.0 kW in its listed electrical configuration, while the product documentation and model designation supplied for this listing specify the 14 kW configuration.
Power Output and Marine Applications
The Paguro 14000 400V generator is designed for users who need dependable three-phase electrical power in a marine environment.
Its 14 kVA / 14 kW, 50 Hz rating makes it suitable for powering a range of onboard electrical loads, depending on the vessel’s electrical architecture and total demand.
The 230/400V three-phase configuration is especially relevant where equipment and systems require three-phase power rather than conventional single-phase supply. Manufacturer documentation lists a 47 A peak-current figure for the 400V three-phase 50 Hz configuration.
Potential applications include commercial vessels, yachts, workboats and other marine installations requiring a dedicated onboard generator.
Engine and Cooling System
At the heart of the Paguro 14000 Generator is a Lombardini 1003 three-cylinder diesel engine.
The generator incorporates a cooling arrangement designed for marine operation, with the engine using fresh-water cooling through a heat exchanger while seawater is used as part of the overall marine cooling circuit. Paguro technical documentation identifies a self-priming cooling pump and heat-exchanger-based engine cooling.
This arrangement helps separate the engine’s internal cooling circuit from direct exposure to seawater, an important consideration for long-term marine engine operation.
The listed specific diesel fuel consumption is approximately 0.35 litres/kWh, providing useful information for evaluating operating requirements.
Quiet Operation and Compact Installation
One of the practical advantages of the Paguro 14000 is its relatively compact footprint.
The generator measures approximately 860 × 580 × 650 mm, allowing it to be considered for installations where available machinery-space volume is limited.
Noise is also an important consideration aboard boats. The Paguro 14000 is listed at approximately 54 dB, with an acoustic casing designed to help control operating noise.
This makes the generator appropriate for installations where maintaining a more comfortable onboard environment is important.
Starting, Controls, and Protection
The Paguro 14000 marine generator uses a 12V electric starting system with remote control, allowing the generator to be operated without requiring direct access to the engine compartment.
The remote control arrangement can include operating information such as running hours and load indication, while protection functions can monitor conditions including oil pressure and engine temperature.
An emergency starting arrangement with a handle and automatic decompressor is also specified in the supplied product information.
These features provide practical advantages for marine installations where accessibility and operational monitoring are important.
Construction and Long-Term Reliability
Marine generators operate in demanding environments where compact dimensions, cooling performance and resistance to operating stresses are important.
The Paguro 14000 combines a Lombardini diesel engine, permanent-magnet generator technology and a sound-insulated enclosure into a compact package.
The permanent-magnet generator configuration provides the electrical generation system with a dedicated design suited to the Paguro package, while the enclosed construction helps protect the system and control operating noise.
For commercial and marine operators, selecting a generator should always involve evaluating electrical load requirements, available installation space, ventilation, cooling arrangements and compatibility with the vessel’s electrical system.
Who This Generator Is Best For
The Paguro 14000 Generator 400V 14 kVA is best suited to buyers who need a compact diesel-powered three-phase generator for marine or other demanding installations.
It can be a strong fit for:
- Commercial and recreational vessels
- Yachts and workboats
- Marine repower and electrical-system projects
- Installations requiring 400V three-phase power
- Applications where controlled generator noise is important
Buyers should confirm the vessel’s electrical requirements and installation specifications before ordering.
Technical Specifications
| Specification | Details |
|---|---|
| Product | Paguro 14000 Generator 400V 14 kVA – 14 kW (50 Hz) 3600 RPM |
| Generator Type | Marine diesel generator |
| Configuration | Three-phase |
| Electrical Output | 14 kVA / 14 kW at 50 Hz |
| Voltage | 230/400V 3-phase |
| Frequency | 50 Hz |
| Engine Manufacturer | Lombardini |
| Engine Model | 1003 |
| Cylinders | 3 |
| Engine Speed | 3,000 rpm at 50 Hz / 3,600 rpm at 60 Hz |
| Cooling | Fresh-water cooling with heat exchanger; marine seawater circuit |
| Cooling Pump | Self-priming |
| Starting System | 12V electric start |
| Control | Remote controlled |
| Specific Fuel Consumption | 0.35 L/kWh |
| Peak Current | 47 A at 400V 3-phase |
| Noise Level | 54 dB |
| Dimensions | 860 × 580 × 650 mm |
| Generator Type | Permanent magnet |
| Weight with Acoustic Casing | 210 kg |
Ordering, Installation, and Support
The Paguro 14000 Generator is a specialized marine power system, so compatibility should be evaluated before purchase.
Customers should verify the required electrical output, voltage, frequency, available installation space, cooling arrangement and vessel requirements before selecting the generator.
The compact dimensions and remote starting system can simplify integration into suitable installations, while the acoustic enclosure helps address noise considerations.
For customers comparing marine generators, the Paguro range also provides alternatives in different output classes, allowing the generator capacity to be matched more closely to the vessel’s actual electrical requirements.
Frequently Asked Questions
What is the Paguro 14000 Generator?
The Paguro 14000 is a compact marine diesel generator designed for continuous electrical power applications. The three-phase version provides 14 kVA at 50 Hz and operates with a 230/400V three-phase electrical configuration.
Is the Paguro 14000 a 400V generator?
Yes. The Paguro 14000 3PH configuration is specified for 230/400V three-phase operation at 50 Hz, making it suitable for electrical systems requiring 400V three-phase power.
How much power does the Paguro 14000 produce?
The product is specified as a 14 kVA / 14 kW generator at 50 Hz. Actual usable electrical capacity should be evaluated against the vessel’s electrical system and the characteristics of the connected loads.
What engine does the Paguro 14000 use?
The Paguro 14000 uses a Lombardini 1003 three-cylinder diesel engine. Manufacturer documentation identifies the 1003 as the engine model used in the 14,000 series.
Does the Paguro 14000 operate at 3,600 rpm?
The manufacturer documentation distinguishes between frequency configurations. The Paguro 14000 operates at 3,000 rpm at 50 Hz and 3,600 rpm at 60 Hz. Therefore, 3,600 rpm corresponds to the 60 Hz configuration rather than the 50 Hz configuration.
How noisy is the Paguro 14000?
The Paguro 14000 is listed at approximately 54 dB, making controlled noise output one of the characteristics of the enclosed generator package.
Is the Paguro 14000 suitable for marine applications?
Yes. The Paguro 14000 is specifically designed as a marine diesel generator, with a marine cooling arrangement, compact enclosure and remote starting system suited to onboard installations.
